Author Topic: Latching Illuminated Switch Question  (Read 3490 times)
AlthaxX
Knight Lieutenant
*

Force Alignment: 65
Posts: 248
« on: May 19, 2013, 12:09:18 AM »
I am about to order a replacement for my busted switch on one of my dominix's i just wanted to make sure it would work.

this is the switch i am going to order:


it says it is a "Brass 16mm Push-button Switch w LATCH 1NO/C 12V"

my dominix is a standard setup with a GB led.

my question is when i wire this switch in will i need any special resistors with it or anything?

thanks in advance for your help.
Logged

Vex
Knight Commander
*

Force Alignment: -402
Posts: 1739
« Reply #1 on: May 19, 2013, 12:39:07 AM »
You will need a resistor and a AV switch bezel.
Logged

dark side points please

AlthaxX
Knight Lieutenant
*

Force Alignment: 65
Posts: 248
« Reply #2 on: May 19, 2013, 01:03:19 AM »
what exactly is a AV switch bezel.
Logged

mcnaughtonM
Knight Lieutenant
*

Force Alignment: -41
Posts: 230


[Darkside points only]
« Reply #3 on: May 19, 2013, 01:18:46 AM »
Quote from: Vex on May 19, 2013, 12:39:07 AM
You will need a resistor and a AV switch bezel.

If you have a hilt that has taken a guarded switch before, will you still need a bezel if it has the drop for the switch?
Logged
Inventory:
- Prophecy in CG
- Dark Liberator in CG (gb)
- Shock in BR (Silver FOC)
- Dominix LE in BR
Wishlist:
- Graflex in GB
- Raven in BR
- Reaper in BR

Zren Tobas
Knight Commander
OVER 9000!!
*********

Force Alignment: -2080
Posts: 14901


[Give Light Side Points!] [Give Dark Side Points!]
« Reply #4 on: May 19, 2013, 03:30:11 AM »
If this works out for you let us know the info. o_o This gives me ideas. Lol. Or just get a non illuminated av switch unless you want it lit.
Logged
Sabers: Liberator V3 CG ObsV4 sound!, Graflex GB, Overlord AB, Crimson Savior BR, Bane PO, Dark Initiate V2 LE BH, Shock GB, Archon V2.1 CG, Dark Sentinel LE GB ObSLite!, Standard Issue V3 CG, Dominix V3 LE BR, Sentinel SRD, Dominix V2 FO, Exile CG

[/url]SW1 by joshgarcia07[/url

Kyaryo Ysoyav
Knight Officer
*

Force Alignment: 19
Posts: 109
« Reply #5 on: May 19, 2013, 05:48:10 AM »
You might want to cross check the length of that switch with the ID of your saber.  My wife has a dominix and they are not as wide as a lot of other sabers.  They do make most of these AV switches in a shorter version.
Logged
Light side points please.

AlthaxX
Knight Lieutenant
*

Force Alignment: 65
Posts: 248
« Reply #6 on: May 19, 2013, 01:48:19 PM »
Thanks for the info, I am going to order it and give it a go. Ill make a thread about the process and if it works when I recive it.
Logged
